Year of manufacture 2008
Working width 230 mm
Planing height 120 mm
Number of spindles 5
Bottom spindles 2
Right spindles 1
Spindles left 1
Spindles top 1
Spindle configuration b-r-l-t-b
Spindle rotation speed max 1/min 6.000 rpm
Spindle diameter 40 mm
Feedrate max 12 m/min
Continuously variable feed
Feed motor 0,25 kW
Main motor power 11 kW
Chip rabbet cutter
Motoric adjustment Programmable controller
Infeed table length 2.000 mm
Lubrication pump manually
Pneumatic top pressure
First infeed roller controlled
Type of feed roller drive Direct drive
Quick tool change WEINIG PowerLock
Quick release systems for tool change 2
CNC-axes Yes
WEINIG Multi function table
Control WEINIG MEMORY-SYSTEM
Declaration of CE-conformity
Conformity marking CE mark
Total connection 34 kW
Weight 2.500 kg
Space requirement Length 3,9 m
Space requirement Width 3 m
Space requirement Height 2,3 m
* motorpower in KW:u-5,5/r,l-7,5/o-7,5/u-11
