high quality industrial setup
rubber-coated wheel for a quiet operation
aluminium fence with quick release function
fence guide with two loupes for precise adjustments and reading
cutting height adjustable via hand wheel and gear rack
windows to check the tension of the saw band
saw band width from 19mm up to 50mm
machine total height 223cm
table angle adjustment (0°-45°) via worm gear
two connectors for dust collection (Ø100mm)
throat / max. cutting width 700mm
max. cutting width at rip fence 440 mm
cutting height at 90° 430 mm
table
- dimensions 700x900 mm
- tilt -5° bis +45°
- height from ground 935 mm
sawband length 5020 mm
sawband width 19 - 50 mm
flywheel diameters 700 mm
motor power S1 (100%) / S6 4.0 kW / 5.6 kW
dust outlet diameter 2x 100 mm
voltage 400 V
net weight approx. 425 kg
shipping weight 442 kg
packaging dimensions 745x2250x1145mm
